Description
Cube Stereo Hybrid 160 HPC Race 750
Cube Stereo Hybrid 160 HPC Race 750 is an electric mountain bike (e-MTB) designed for enduro riding and challenging terrains. Elysium Bike-(elysiumbike.com):
AUSSTATTUNG (Components)
FRAME
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4‑Link, Agile Trail Geometry, Boost 148, UDH™, Fully Integrated Battery, Advanced Internal Cable Routing
SIZE
27.5: S M L XL
SUSPENSION FORK
RockShox Domain R, Tapered, 15×110 mm, eMTB Approved, 170 mm
SHOCK
RockShox Deluxe Select, 205×65 mm, Rebound Adjust, Trunnion Mount
SHOCK HARDWARE
Top: 54 mm Trunnion Mount, Bottom: 22.2×8 mm
BRAKE SYSTEM
Magura MT Thirty, Front 4‑Piston/Rear 4‑Piston, Hydr. Disc Brake (203/203)
REAR DERAILLEUR
Shimano Deore RD‑M6100‑SGS, ShadowPlus, 12‑Speed
SHIFTERS
Shimano Deore SL‑M6100, Rapidfire‑Plus
CRANKSET
ACID E‑Crank, 165 mm, 36 T
CHAIN GUIDE
Reverse Flip‑Guide E‑Chain Guide, Direct Mount, GEN4
CASSETTE
Shimano Deore CS‑M6100, 10‑51 T
CHAIN
Shimano CN‑M6100
FRONT HUB
Shimano HB‑MT400‑B, 15 mm, Boost, Centerlock
REAR HUB
Shimano FH‑MT410‑B, 12 mm, Boost, Centerlock
RIMS
CUBE EX30, 32 H, Disc, Tubeless Ready
FRONT TYRE
Maxxis Minion DHF, Dual/EXO, Tubeless Ready, 2.5 WT
REAR TYRE
Maxxis Minion DHR II, Dual/EXO, Tubeless Ready, 2.4 WT
STEM
CUBE Performance Stem E‑MTB, 31.8 mm
HANDLEBAR
Newmen Evolution SL 318.25, 780 mm
GRIPS
ACID React Pro
SEAT POST
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6 mm
SADDLE
Natural Fit Venec
GEOMETRIE (Geometry)
For sizes M (20″), L (22″), XL (22″) (27.5″ wheels):
| Size | M (20″) | L (22″) | XL |
|---|---|---|---|
| Reach (A) | 453.4 mm | 479.8 mm | 504.5 mm |
| Stack (B) | 616.1 mm | 626.9 mm | 643.3 mm |
| Standover (C) | 769.9 mm | 769.3 mm | 792.6 mm |
| Effective Top Tube (D) | 600 mm | 630 mm | 660 mm |
| Head Tube Angle (E) | 65° | 65° | 65° |
| Head Tube Length (F) | 120 mm | 132 mm | 150 mm |
| Seat Tube Angle (G) | 76° | 76° | 76° |
| Seat Tube Length (H) | 420 mm | 460 mm | 490 mm |
| Bottom Bracket Drop (J) | 12.5 mm | 12.5 mm | 12.5 mm |
| Wheelbase (M) | 1224.7 mm | 1256.2 mm | 1288.5 mm |
| Chainstay Length (O) | 441.5 mm | 441.5 mm | 441.5 mm |
Frame:
- Material: High-Performance Composite (HPC), carbon frame with an aluminum rear triangle
- Design: Full-suspension frame optimized for enduro riding
- Rear Travel: 160mm
- Battery Integration: Fully integrated for a sleek design
Suspension:
- Fork: RockShox Domain R, 170mm travel
- Rear Shock: RockShox Deluxe Select, 160mm travel
- Suspension Type: Full suspension to handle rough trails and jumps
Motor and Battery:
- Motor: Bosch Performance Line CX Generation 4 (85Nm), powerful and responsive motor for steep climbs
- Battery: Bosch PowerTube 750Wh, providing extended range
- Display: Bosch Purion for ride control and battery status
Drivetrain:
- Shifter: SRAM NX Eagle
- Rear Derailleur: SRAM NX Eagle, 12-speed
- Cassette: SRAM PG-1210 Eagle, 11-50T
- Chain: SRAM NX Eagle
Brakes:
- Type: Hydraulic disc brakes
- Brand: Shimano BR-MT520
- Rotors: 203mm front and rear for reliable stopping power
Wheels:
- Rims: Newmen Performance 30, tubeless-ready
- Tires: Schwalbe Magic Mary, 2.6-inch front and rear, Addix Soft compound for grip on various terrains
Additional Features:
- Dropper Post: CUBE Dropper Post, handlebar remote
- Cockpit: Newmen handlebar and stem for a comfortable and controlled ride
- Pedals: Sold separately
- Weight: Approximately 25.1kg (varies by frame size)
Target Rider:
Ideal for riders looking for a powerful and capable e-MTB to tackle demanding trails, steep climbs, and technical descents.
